Dahua PFS3106-4ET-60 4-poorts Unmanaged PoE Switch, 4 × RJ45 10-100M, 60W

Merken: Dahua Technology
Artikelnr #:PFS3106-4ET-60 Model #: DH-PFS3106-4ET-60-V2  Naam: Dahua PFS3106-4ET-60 4-Port Unmanaged PoE Switch, 4 × RJ45 10-100M, 60W
  • Two-layer industrial PoE switch
  • MAC auto study and aging, MAC address list capacity is 8K
  • Support IEEE802.3af, IEEE802.3at standard
Dahua PFS3106-4ET-60 4-Port Unmanaged PoE Switch, 4 Ч RJ45 10-100M, 60W

Productoverzicht

Algemeen Informatie

Main Features

  • PFS3106-4ET-60
  • 4-port PoE Switch
  • PoE Budget: 60 W
  • 30 Watt / Port
Main Features
  • Two-layer industrial PoE switch
  • MAC auto study and aging, MAC address list capacity is 8K
  • Support IEEE802.3af, IEEE802.3at standard
  • Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and IEEE802.3X standards
  • Industrial wide temperature design
  • Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
  • Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
  • Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
Informatie
Categorie : Data Comm & Netwerken, Producten, Hubs, Routers & Switches, Netwerk Switches

Specificaties

Algemene Informatie
ADI artikel nummer
PFS3106-4ET-60
Artikelcode fabrikant
DH-PFS3106-4ET-60
Fabrikant
Zhejiang Dahua Technology Co., Ltd.
Merk
Dahua
Productmodel
DH-PFS3106-4P-60
Productnaam
4-Port PoE Switch (Unmanaged)
Producttype
Ethernetswitch
Weight (Approximate) (g)
48
Technische Informatie
Ondersteund mediatype
Twisted-pair
Stroomverbruik
60 W
Energie
Stroombron
Gemakkelijk te gebruiken
I/O-uitbreidingen
Aantal SFP slots
1
Aantal Total Expansion slots
1
Type uitbreidingsslot
SFP (mini-GBIC)
Interfaces/Poorten
Gegevens poort/uitbreidingssleuf
1 x Gigabit Ethernet Expansion Slot, 1 x Gigabit Ethernet Uplink, 4 x Fast Ethernet PoE
Totaal aantal netwerkpoorten
4
Uplink-poort
Ja
Interfaces/Ports
Modulair
Ja
Management & Protocollen
Beheer mogelijk
Nee
Media & Performance
Netwerktechnologie
10/100/1000Base-T, 10/100/1000Base-TX, 1000Base-X
Netwerk & Communicatie
Maximaal aantal lagen
3
Network & Communication
Ethernet technologie
SFP, Snel internet
Power Description
PoE (RJ-45) poort
Ja
Power Consumption (W)
60.000
Uiterlijke kenmerken
Breedte
150 mm
Depth (mm)
100
Diepte
100 mm
Gewicht (bij benadering)
48 g
Height (mm)
30
Hoogte
30 mm
Width (mm)
150
